stainless steel wire cloth and wire mesh

stainless steel wire cloth and wire mesh

Inquire Now

Product details

Stainless steel wire mesh is also called stainless steel screen,stainless steel weaving wire mesh

stainless steel strainer,stainless steel filter mesh,stainless steel wide wire mesh etc.

Product Description:

Some steels are exceptionally tough at very low temperatures while other alloys maintain strength at very high temperatures.

Stainless steel wire mesh cloth is selected for their wear-resisting, heat-resisting, acid-resisting and corrosion resisting characteristics. Many different grades of stainless are used in wire cloth. SS304 is the most common material, the others are used in specific applications to take advantage of each grades' unique properties.

Popular Weaving Types for Wire Mesh:

Plain Weave, Twilled Weave, Dutch Plain Weave, Dutch Twilled Weave, Reverse Dutch Weave and Five Heddle Weave.

We produce Stainless steel wire mesh cloth in all kinds of forms. The weaving is determined according to our customers' specific requirements, such as the material, the wire diameter, the size of the mesh , width and length.

Materials:

Our stainless steel wire mesh products are generally made of stainless steel Type 201,302, 304, 304L, 310,310s,316, 316L, 321 and 430 etc.

Feature:

Most of the stainless steels can easily be manufactured with various weaving types in the weaving looms.Stainless steel wire meshes can withstand various weather conditions and have a highly aesthetic appeal when it comes to architectural applications, like fencing and wall decoration.Stainless steel is easy to maintain when it comes to the hygienic characteristics and clean ability, this is why stainless steel is also applied within the pharmaceutical- and food industry.Stainless steel wire mesh is highly durable and can withstand severe circumstances over a long period of time. Which means that stainless steel can be categorized as a low maintenance material, thus this is usually a cost-effective choice in terms of a life cycle comparison with regard to costs.

Application:

The wire mesh made of stainless steel is extensively used in mining , chemical industry, food industry and pharmaceutical industry.

Packaging :Wooden box

Our Service:Materials certificationCustomized size

Specifications:Woven wire mesh size as below.

Mesh	Wire diameter		Aperture
Mesh	Inch	mm	Inch	mm
1x1	0.08	2.03	0.92	23.37
2X2	0.063	1.6	0.437	11.1
3X3	0.054	1.37	0.279	7.09
4X4	0.063	1.6	0.187	4.75
4X4	0.047	1.19	0.203	5.16
5X5	0.041	1.04	0.159	4.04
6X6	0.035	0.89	0.132	3.35
8X8	0.028	0.71	0.097	2.46
10X10	0.025	0.64	0.075	1.91
10X10	0.02	0.51	0.08	2.03
12X12	0.023	0.584	0.06	1.52
12X12	0.02	0.508	0.063	1.6
14X14	0.023	0.584	0.048	1.22
14X14	0.02	0.508	0.051	1.3
16X16	0.018	0.457	0.0445	1.13
18X18	0.017	0.432	0.0386	0.98
20X20	0.02	0.508	0.03	0.76
20X20	0.016	0.406	0.034	0.86
24X24	0.014	0.356	0.0277	0.7
30X30	0.013	0.33	0.0203	0.52
30X30	0.012	0.305	0.0213	0.54
30X30	0.009	0.229	0.0243	0.62
35X35	0.011	0.279	0.0176	0.45
40X40	0.01	0.254	0.015	0.38
50X50	0.009	0.229	0.011	0.28
50X50	0.008	0.203	0.012	0.31
60X60	0.0075	0.191	0.0092	0.23
60X60	0.007	0.178	0.0097	0.25
70X70	0.0065	0.165	0.0078	0.2
80X80	0.0065	0.165	0.006	0.15
80X80	0.0055	0.14	0.007	0.18
90X90	0.005	0.127	0.0061	0.16
100X100	0.0045	0.114	0.0055	0.14
100X100	0.004	0.102	0.006	0.15
100X100	0.0035	0.089	0.0065	0.17
110X110	0.004	0.1016	0.0051	0.1295
120X120	0.0037	0.094	0.0064	0.1168
150X150	0.0026	0.066	0.0041	0.1041
160X160	0.0025	0.0635	0.0038	0.0965
180X180	0.0023	0.0584	0.0033	0.0838
200X200	0.0021	0.0533	0.0029	0.0737
250X250	0.0016	0.0406	0.0024	0.061
270X270	0.0016	0.0406	0.0021	0.0533
300X300	0.0051	0.0381	0.0018	0.0457
325X325	0.0014	0.0356	0.0017	0.0432
400X400	0.001	0.0254	0.0015	0.37
500X500	0.001	0.0254	0.001	0.0254
635X635	0.0008	0.0203	0.0008	0.0203
(Available in stainless steel 304, 304L, 316 & 316L grade)
