PVC Coated iron Wire

Product details
PVC Coated Iron Wire

Brief introduction

PVC coated iron wire is a layer of polyvinyl chloride or polyethylene attached to the surface of annealed wire, galvanized wire and other materials. The coating firmly and evenly adheres to the metal wire, forming anti-aging, anti-corrosion, anti-cracking and long life. pvc covered wire can be used as bundling wire for daily life bundling and industrial bundling. pvc covered wire can also be used for wire frame or craft production.PVC Coated Wire is made from high quality iron wire. PVC is the most popular plastic for coating wires,as it is relatively low in cost,resilient,fire retardant and possesses good insulating properties.Common colors available for PVC coated wire are green and black. Other colors also available on request.

 Quick details

ProductsPVC Coated Iron Wire
Tensile strength350mpa-550mpa (SOFT) 600Mpa-900Mpa(HARD)
Elongation8% - 15%
Coating typePVC, PE (on request)
Coating Colorgreen, black, white, gray etc on request
Packageplastic inside and hessian woven outsidePlastic inside and nylon woven outside
Application industrial security fences, animal cultivation, stadium, freeways and tennis courts.



Prevent steel wire agingstrong corrosion resistanceprevent steel wire crackingLong service lifeFlexibility Different diameter Different weight of box or cartonRust-resistantDifferent colors


It is widely used in animal breeding, agriculture and forestry protection, aquaculture, parks, zoo pens, stadiums and so on.The most popular use for PVC coated wire is in the construction of chain link fences for industrial security fences, freeways and tennis courts. It is also used in other applications such as coat hangers and handles.


Wire gauge8#-24#, 4mm-0.55mm
Plastic thickness0.4mm-1.0mm
Wire tolerance+0.05mm/-0.05mm Max
CoatPVC, vinyl or PE (on request)
Colorgreen, black, white, grey and etc (on request).
Tensile strength  350N/MM2-550N/MM2(soft)600N/MM2-900N/MM2(hard);



Specification of PVC Coated Wire
Inner Core wire: Galvanized wire, black iron wire, Stainless steel wire, etc
Core wire diameterDiameter after coated
1. lined with P.V.C strips and wrapped with PVC or hessian cloth
2. small coils of 50m, 100m, 150m, 200m, and so on
3.Color: RAL 6005, 6009 etc.
4.Diameters: many others available as per buyers' request.

Note:Special specification can be customized
